Features:
Compared to 316L and 317L austenitic stainless steel, S31803 duplex stainless steel is superior at pitting corrosion and crevice corrosion resistance. It has excellent corrosion resistance. Compared to austenitic, it is with lower thermal expansion coefficient and higher thermal conductivity. S31803 duplex stainless steel wire mesh is widely used in chemistry, seawater desalination equipment
Pressure vessels, tanks, high pressure pipe, heat exchanger( chemical processing industry)
Oil and gas pipelines, heat exchangers pipe fittings
Sewage treatment system
Food processing equipment etc
Chemical Composition
|
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
N |
ASTM A240/UNS S31803 |
≤0.03 |
≤1.00 |
≤2.00 |
≤0.03 |
≤0.02 |
4.5-6.5 |
21.0-23.0 |
2.5-3.5 |
0.08-0.20 |
ASTMA240/UNS S32205 |
≤0.03 |
≤1.00 |
≤2.00 |
≤0.03 |
≤0.02 |
4.5-6.5 |
22.0-23.0 |
3.0-3.5 |
0.14-0.20 |
Woven Technique: Plain Weave
Mesh Count: 2-200 MESH
Applications of UNS S31803(S32205) Duplex Stainless Steel Wire Mesh:
Pressure vessels, tanks, high pressure pipe, heat exchanger( chemical processing industry)
Oil and gas pipelines, heat exchangers pipe fittings
Sewage treatment system
Food processing equipment etc
Specifications:
UNS S32304 Wire Mesh |
Mesh Count |
Wire diameter(mm) |
Aperture(mm) |
Max width(m) |
10 |
0.60 |
1.94 |
1.60 |
20 |
0.40 |
0.87 |
1.60 |
30 |
0.30 |
0.55 |
1.60 |
40 |
0.23 |
0.40 |
1.60 |
50 |
0.20 |
0.31 |
1.60 |
60 |
0.15 |
0.27 |
1.60 |
70 |
0.12 |
0.24 |
1.60 |
80 |
0.13 |
0.19 |
1.60 |
90 |
0.12 |
0.16 |
1.60 |
100 |
0.10 |
0.15 |
1.60 |
120 |
0.09 |
0.12 |
1.60 |
150 |
0.063 |
0.11 |
1.60 |
180 |
0.053 |
0.01 |
1.60 |
200 |
0.053 |
0.07 |
1.60 |
Note: Special size and specification can be customized.
